Known problems and limitations
This section gives a list of bugs and limitations that were known at the time of the last release of JaxoDraw. Please check the Bugs in our Issue Management for an updated list. Note that not all points are necessarily real bugs, we regard this just as a collection of features that do not work exactly the way we would like to.
Bugs
- Gluon Beziers have wrong number of wiggles: the number of wiggles drawn on screen does not correspond to the number specified in the edit panel. See bug #75.
- Zigzag loops do not have a continuous first derivative at the 2nd click point. See bug #96.
- Some Swing internal components do not (yet) allow full internationalization. For JaxoDraw, this effects only some text fields in the FileChooser, ColorChooser and Print dialogs, where the text will always be given in English.
- Menu accelerator keys are always shown in the language of the system's locale. See bug #95.
- When drawing an object, clicking once outside the drawing area will make the object disappear. See bug #60.
- When grouping some objects where one object is attached to an object outside the group, that attachment is lost.
- Scrolling only works within the limits of the largest available screen size. In particular, if a graph is opened that was created on a larger device, the object's edit points may not be reachable.
Wish list
Any feature request or suggestions should be filed at our SourceForge Request page.
